SMT Type 5 Pin USB C Connector 4.85mm Straight Side With Horn For Smart Lock

SMT Type 5 Pin USB C Connector 4.85mm Straight Side With Horn For Smart Lock
SMT Type 5 Pin USB C Connector 4.85mm Straight Side With Horn For Smart Lock

Large Image :  SMT Type 5 Pin USB C Connector 4.85mm Straight Side With Horn For Smart Lock

Product Details:

Place of Origin: Guangdong,China(Mainland)
Brand Name: DALEE
Certification: ROHS ,SGS, ISO9001
Model Number: DL50010315

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: PE bag, Tube, Volume
Delivery Time: 5-10 days
Payment Terms: T/T, L/C
Supply Ability: 1000KK/month
Detailed Product Description
Gender: Female Pin: 5 P
Application: Smart Lock Operating Temprature: -25℃ - +85 ℃
Type: Micro Housing: Thermoplastic , UL94 V-0
High Light:

micro usb connector

,

mini usb connector

Micro USB Cable Connectors SMT type 5 Pin 4.85mm Straight side with horn for smart lock





Product Details:



Product name: DALEE USB Type-C Connector
Secification:  5 P
Type :  Micro USB
Certification: ISO9001,UL,ROHS and the latest REACH
Insertion Force: 0.5~2.0kgf
Removal Force: 0.8~2.0kgf
Durability: 10000 cycles
Current Rating: 3.0A
Voltage Rating: 5.0 V
Current Rating: 1.0A
Shield: 50mΩ /MAX
Insulation Resistance: 100mΩ/MIN
Operating Temprature: -25℃ - +85 ℃
Contacts: Copper Alloy
Housing: Thermoplastic , UL94 V-0





Material Specification:



 1) Mid Plate: stainless steel

 2) Housing: Hig Temperature resistant plastic,UL94 V-0.

 3) Solder area: Au : G/F

 4) Front shell : stainless steel





Drawing:



SMT Type 5 Pin USB C Connector 4.85mm Straight Side With Horn For Smart Lock 0





Product Application:   Dalee connectors are  widely applied to lots of industries, such as computer peripheral products ,cusumer electronics, action camera manual mini sport DV, rear DVR video recorder , unmanned aerial vehicle, cummunications industry ,military industry ,automotive filed, medical equipment and so on .





Competitive Advantages:



1, More than 10 year's experience in the electronic business.

2, Quality certification ,including ROHS,SGS,ISO9001 and UL certification.

3, samples can be provided for free in 1-3 days .

4, we also can provide the customized products as the request of clients

5, Strict shipping ,100% tested before delivery

6, fast delivery,purchasing orders shipped in 3-10 days





Payment term and delivery:



1. MPQ:1000pcs

2. Trade Terms: FOB Shenzhen or EXW.

3. Payment term: 100% T/T in advance before production.

4. Payment way: T/T, Paypal , Western Union or others method.

5. Shipping method: UPS, DHL, FEDEX,EMS& Air transportation& Sea transportation..
